Cable connector tool Aviation plug SY21 Support samples

Short Description:

Aviation Connector Socket and Switch,SY21
Coupling:Bayonet
Shell material:PC,Nylon66,fire resistance:V-0
Insert material:PPS,max temperature 260℃
Termination:Screw(SY21ø3mm contact)/Solder/Crimp
Cable outer diameter range:SY21[Ⅰ:4.5-7mmⅡ:7-12mm(Not marked)]
IP range:IP67,Temperature range:-40℃~ 85℃
Insulation resistance:2000MΩ
Mating cycle:500
Contact material:Brass with gold plating
Widely used in various machine tools, locomotives, electricity, post and telecommunications, communications,navigation, instrumentation, lighting systems, medical and oil exploration and other fields.


Product Detail

Product Tags

wef

Cable connector
Mate with SY2111,SY2112,SY2113
SY2110/P_ _ _

ht (1)

Angled Cable connector
Mate with SY2111, SY2112,SY2113
SY2114/P_ _ _

ht (2)
1
ht (3)

In-line cable connector
Mate with SY2110
SY2111/S_ _ _

ht (4)

Rear-nut mount
Mate with SY2110
SY2112/S_ _ _

ht (5)

Square flange
Mate with SY2110
SY2113/S_ _ _

Cable connector
Mate with SY2111, SY2112,SY2113
SY2110/S_ _ _

ger (1)

Angled Cable connector
Mate with SY2111,SY2112,SY2113
SY2114/S_ _ _

ger (2)
2
ger (3)

In-line cable connector
Mate with SY2110
SY2111/P_ _ _

ger (4)

Rear-nut mount
Mate with SY2110
SY2112/P_ _

ger (5)

Square flange
Mate with SY2110
SY2113/P_ _
④⑤

①Number of contact
②Cable outer diameter:Ⅰ:4.5-7mm Ⅱ:7-12mm
③1:solder, 2:screw,3:crimp

④Number of contact
③1:solder, 2:screw,3:crimp
⑤1:solder, 2:screw,3:crimp

Material and spec

Material Plastic
IP Rating IP67
Coupling Type Bayonet Coupling
Shell Nylon66,fire resistance:V-0
Insert material PPS max temperature 260℃fire resistance:V-0
Contact material Brass with gold plating
Termination Solder/Screw/Crimp
Cable outer diameter range I4.5-7mm    II7-12mm
Mating cycle > 500
Temperature range -25℃~+85℃
Insulation resistance MΩ 2000
Material Plastic

Contact arrangement and spec for solder/screw

Number of contact

2

3

4

5

5B

5C

7

9

12

Male contact face view

 rt (1)

rt (2)

 rt (3)

 rt (4)

rt (5)

rt (6)

 rt (7)

rt (8)

 rt (9)

Rated current (A)

30A

30A

30A

30A

5A、30A

15A

15A

5A

5A

Contact diameter

 3×2

 3×3

 3×4

 3×5

 1×3
 3×2

 2×5

 2×7

 1×9

 1×12

Termination

solder
screw

solder
screw

solder
screw

solder
screw

solder
screw

solder

solder

solder

solder

Rated voltage(AC.V)

500V

500V

500V

500V

500V

500V

500V

500V

400V

Test voltage(AC.V)
1 min

1500V

1500V

1500V

1500V

1500V

1500V

1500V

1500V

1200V

Contact resistance mΩ

1

1

1

1

5、1

2.5

2.5

5

5

Wire size mm² /AWG

≤4.17/11

≤4.17/11

≤4.17/11

≤4.17/11

≤0.785/18
≤4.17/11

≤2/14

≤2/14

≤0.785/18

≤0.785/18

Crimp contact arrangement and spec

Number of contact

2

3

5

7

8

Male contact face view

rt (1)

 rt (2)

rt (3)

 rt (4)

rt (5)

Rated current (A)

25A

25A

10A

10A

5A

Contact diameter

 2.5×2

 2.5×3

 1.5×5

 1.5×7

 1×8

Rated voltage(AC.V)

500V

500V

500V

500V

500V

Test voltage(AC.V)1 min

1500V

1500V

1500V

1500V

1500V

Contact resistance mΩ

1

1

2.5

2.5

5

Insulation resistance mΩ

2000

2000

2000

2000

2000
