SY2113/P 2-hole flange Mate with SY2110/S

Short Description:


Product Detail

Product Tags

SY2113P



Material and spec

Material Plastic
IP Rating IP67
Coupling Type Bayonet Coupling
Shell Nylon66,fire resistance:V-0
Insert material PPS max temperature 260℃fire resistance:V-0
Contact material Brass with gold plating
Termination Solder/Screw/Crimp
Cable outer diameter range I4.5-7mm    II7-12mm
Mating cycle > 500
Temperature range -25℃~+85℃
Insulation resistance MΩ 2000
Material Plastic

Contact arrangement and spec for solder/screw

Number of contact

2

3

4

5

5B

5C

7

9

12

Male contact face view

 rt (1)

rt (2)

 rt (3)

 rt (4)

rt (5)

rt (6)

 rt (7)

rt (8)

 rt (9)

Rated current (A)

30A

30A

30A

30A

5A、30A

15A

15A

5A

5A

Contact diameter

 3×2

 3×3

 3×4

 3×5

 1×3
 3×2

 2×5

 2×7

 1×9

 1×12

Termination

solder
screw

solder
screw

solder
screw

solder
screw

solder
screw

solder

solder

solder

solder

Rated voltage(AC.V)

500V

500V

500V

500V

500V

500V

500V

500V

400V

Test voltage(AC.V)
1 min

1500V

1500V

1500V

1500V

1500V

1500V

1500V

1500V

1200V

Contact resistance mΩ

1

1

1

1

5、1

2.5

2.5

5

5

Wire size mm² /AWG

≤4.17/11

≤4.17/11

≤4.17/11

≤4.17/11

≤0.785/18
≤4.17/11

≤2/14

≤2/14

≤0.785/18

≤0.785/18

Crimp contact arrangement and spec

Number of contact

2

3

5

7

8

Male contact face view

rt (1)

 rt (2)

rt (3)

 rt (4)

rt (5)

Rated current (A)

25A

25A

10A

10A

5A

Contact diameter

 2.5×2

 2.5×3

 1.5×5

 1.5×7

 1×8

Rated voltage(AC.V)

500V

500V

500V

500V

500V

Test voltage(AC.V)1 min

1500V

1500V

1500V

1500V

1500V

Contact resistance mΩ

1

1

2.5

2.5

5

Insulation resistance mΩ

2000

2000

2000

2000

2000
