Cable connector tool Aviation plug SF12 Support samples

Short Description:

Aviation Connector Socket and Switch,SF12,Coupling:Push-pull,Shell material:Brass with chrome planting,Insert material:PPS,max temperature 260℃,Cable outer diameter range:[Ⅰ:4-6.5mm(Not marked)Ⅱ:5-8mm],IP range:IP67,Temperature range:-40℃~ 85℃,Insulation resistance:2000MΩ,Mating cycle:500,Contact material:Brass with gold plating,Termination:Solder
Widely used in various machine tools, locomotives, electricity, post and telecommunications, communications,navigation, instrumentation, lighting systems, medical and oil exploration and other fields.


Product Detail

Product Tags

erg

Cable connector
Mate with SF1211, SF1212,SF1213
SF1210/P_ _

rth (1)

Angled Cable connector
Mate with SF1211, SF1212,SF1213
SF1214/P_

rth (2)
2上3下
rth (3)

In-line cable connector
Mate with SF1210
SF1211/S_ _

rth (4)

Rear-nut mount
Mate with SF1210
SF1212/S_ _

rth (5)

Square flange
Mate with SF1210
SF1213/S_ _

Cable connector
Mate with SF1211, SF1212,SF1213
SF1210/S_ _ _
① ②

jyt (1)

Angled Cable connector
Mate with SF1211, SF1212,SF1213
SF1214/S_

jyt (2)
2上3下
jyt (3)

In-line cable connector
Mate with  SF1210
SF1211/P_ _

jyt (4)

Rear-nut mount
Mate with SF1210
SF1212/P_ _

jyt (5)

Square flange
Mate with SF1210
SF1213/P_ _
④⑤

①Number of contact:2.3.4.5.6.7.9
②Cable outer diameter:Ⅰ: 4-6.5mm Ⅱ:5-8mm
③Number of contact:2.3.4.5.6.7.9

Material and spec

Material Metal
IP Rating IP67
Coupling Type Push and Pull
Termination Solder , Screw , Crimp ,
Shell Brass with chrome plating
Insert material PPS, max temperature 260℃
Contact material Brass with gold plating
Termination Solder/Screw/Crimp
Cable outer diameter range I: 8-12mm
Mating cycle > 500
Temperature range -40℃~+85℃
Insulation resistance MΩ 2000

Contact arrangement and spec for solder termination

Number of contact

2

3

4

5

6

7

9

Male contact face view

 hrt (1)

 fr (2)

qqq

 qqqq

s1 (1)

s1 (2)

 s1 (3)

Rated current (A)

13A

13A

5A

5A

5A

5A

3A

Contact diameter

 1.6×2

 1.6×3

 1×4

 1×5

 1×6

 1×7

 0.7×9

Rated voltage(AC.V)

250V

250V

200V

180V

125V

125V

125V

Test voltage(AC.V)1 min

1500V

1500V

1500V

1000V

1000V

1000V

1000V

Contact resistance mΩ

2

2

5

5

5

5

10

Wire size mm² /AWG

≤2/14

≤2/14

≤0.785/18

≤0.785/18

≤0.785/18

≤0.785/18

≤0.785/18
