Short Description:

Aviation Connector Socket and Switch,SA20
Coupling:Push-pull
Shell material:Anodized aluminium
Insert material:PPS,max temperature 260℃
Cable outer diameter range:8-12mm,IP range:IP67
Temperature range:-40℃~ 85℃
Insulation resistance:2000MΩ
Mating cycle:500
Contact material:Brass with gold plating
Termination:Solder/Crimp/Screw
Widely used in various machine tools, locomotives, electricity, post and telecommunications, communications,navigation, instrumentation, lighting systems, medical and oil exploration and other fields.


Product Detail

Product Tags

vx

Cable connector
Mate with SA2011, SA2012,SA2013
SA2010/P_ _

mhj (1)
1上3下:大
mhj (2)

In-line cable connector
Mate with SA2010
SA2011/S_ _

mhj (3)

Rear-nut mount
Mate with SA2010
SA2012/S_ _

mhj (4)

Square flange
Mate with SA2010
SA2013/S_ _

Cable connector
Mate with SA2011, SA2012,SA2013
SA2010/S_ _ _
①②③④

mhj (5)
1上3下:大
mhj (6)

In-line cable connector
Mate with  SA2010
SA2011/P_ _

mhj (7)

Rear-nut mount
Mate with SA2010
SA2012/P_ _

mhj (8)

Square flange
Mate with SA2010
SA2013/P_ _
⑤⑥⑦

①Number of contact
②Cable outer diameter: Ⅰ:8-12mm
③Colour:
B:Black
S:Silver
L:Blue (special order)
G:Green(special order)
R:Red (special order)
④1:solder,2:screw,3:crimp

⑤ Number of contact
⑥Colour:
B:Black
S:Silver
L:Blue (special order)
G:Green(special order)
R:Red (special order)
⑦1:solder,2:screw,3:crimp

Material and spec

Material Metal
IP Rating IP67
Coupling Type Push and Pull
Termination Solder
Shell Anodized aluminium
Insert material PPS, max temperature 260℃
Contact material Brass with gold plating
Termination Solder
Cable outer diameter range Ⅰ: 4-6.5mm Ⅱ: 5-8mm
Mating cycle > 500
Temperature range -40℃~+85℃
Insulation resistance MΩ 2000

Number of contact

2

3

4

5

6

7

9

12

Male contact face view

jty (1)

jty (2)

jty (3)

jty (4)

jty (5)


jty (6)

jty (7)

 jty (8)

Rated current (A)

25

25

25

10

25
5

10

5

5

Contact diameter(mm)

2.25

2.5

2.5

1.5

φ2.5X4
φ1X2

1.5

1

1

Rated voltage(AC.V)

500

500

500

500

500

500

500

400

Test voltage(AC.V)1 min

1500

1500

1500

1500

1500

1500

1500

1200

Contact resistance (mΩ)

1

1

1

2.5

1
5

2.5

5

5

Termination

solder/screw

solder/screw

solder/screw

solder

solder

solder

solder

solder

Wire size (mm² /AWG)

≤4/11

≤4/11

≤4/11

≤2/14

≤4/11
≤0.785/18

≤2/14

≤0.785/18

≤0.785/18

Wire size for screw termination (mm² /AWG)

≤1.5/15

≤1.5/15

≤1.5/15

/

/

/

/

/

Number of contact

2

3

4

5

7

7B

8

Male contact face view

jty (1)

jty (2) hrt (1) hrt (2)

hrt (3)

hrt (4)

hrt (5)

Rated current (A)

25

25

25

10

10

5

5

Contact diameter(mm)

2.5

2.5

2.5

1.5

1.5

1

1

Rated voltage(AC.V)

500

500

500

500

500

400

400

Test voltage(AC.V)1 min

1500

1500

1500

1500

1500

1200

1200

Contact resistance (mΩ)

1

1

1

2.5

2.5

5

5

Insulation resistance (MΩ)

2000

2000

2000

2000

2000

2000

2000
