Cable connector

Mate with SF2011, SF2012,SF2013

SF2010P_-_

60

61

62

63

64

In-line cable connector

Mate with SF2010

Rear-nut mount

Mate with SF2010

Square flange

Mate with SF2010

SF2011/S_ _-_

SF2012/S_-_

SF20131S_-_

Cable connector

Mate with SF2011, SF2012,SF2013

SF2010S_-_

65

 66

 67

 68

69

In-line cable connector

Mate with SF2010

Rear-nut mount

Mate with SF2010

Square flange

Mate with SF2010

SF2011/P_ _ -_

SF2012/P_-_

SF20131P_-_

       ①②③



         ④⑤

Number of contact

1: solder. 2: screw, 3: crimp

Cable outer diameter: : 8-12mm



Number of contact



1: solder. 2: screw, 3: crimp





Material and spec

Material Metal
IP Rating IP67
Coupling Type Push and Pull
Termination Solder , Screw , Crimp ,
Shell Brass with chrome plating
Insert material PPS, max temperature 260℃
Contact material Brass with gold plating
Termination Solder/Screw/Crimp
Cable outer diameter range I: 8-12mm
Mating cycle > 500
Temperature range -40℃~+85℃
Insulation resistance MΩ 2000

Number of contact

2

3

4

5

6

7

9

12

Male contact face view

 70

71

72

73

74

75

76

77

Rated current (A)

25

25

25

10

25
5

10

5

5

Contact diameter(mm)

2.25

2.5

2.5

1.5

φ2.5X4
φ1X2

1.5

1

1

Rated voltage(AC.V)

500

500

500

500

500

500

500

400

Test voltage(AC.V)1 min

1500

1500

1500

1500

1500

1500

1500

1200

Contact resistance (mΩ)

1

1

1

2.5

1
5

2.5

5

5

Termination

solder/screw

solder/screw

solder/screw

solder

solder

solder

solder

solder

Wire size (mm² /AWG)

≤4/11

≤4/11

≤4/11

≤2/14

≤4/11
≤0.785/18

≤2/14

≤0.785/18

≤0.785/18

Wire size for screw termination (mm² /AWG)

≤1.5/15

≤1.5/15

≤1.5/15

/

/

/

/

/

Number of contact

2

3

4

5

7

7B

8

Male contact face view

80

81

82

83

84

85

86

Rated current (A)

25

25

25

10

10

5

5

Contact diameter(mm)

2.5

2.5

2.5

1.5

1.5

1

1

Rated voltage(AC.V)

500

500

500

500

500

400

400

Test voltage(AC.V)1 min

1500

1500

1500

1500

1500

1200

1200

Contact resistance (mΩ)

1

1

1

2.5

2.5

5

5

Insulation resistance (MΩ)

2000

2000

2000

2000

2000

2000

2000
