Short Description:

Aviation Connector Socket and Switch,SA16
Coupling:Push-pull
Shell material:Anodized aluminium
Insert material:PPS,max temperature 260℃
Cable outer diameter range:[Ⅰ:5-8mm(Not marked)Ⅱ:8-12mm]
IP range:IP67
Temperature range:-40℃~ 85℃
Insulation resistance:2000MΩ
Mating cycle:500
Contact material:Brass with gold plating
Termination:Solder/Crimp
Widely used in various machine tools, locomotives, electricity, post and telecommunications, communications,navigation, instrumentation, lighting systems, medical and oil exploration and other fields.

Send email to us Download as PDF

Product Detail

Product Tags

Cable connector
Mate with SA1611, SA1612,SA1613
SA1610/P_ _

In-line cable connector
Mate with SA1610
SA1611/S_ _

Rear-nut mount
Mate with SA1610
SA1612/S_ _

Square flange
Mate with SA1610
SA1613/S_ _

Cable connector
Mate with SA1611, SA1612,SA1613
SA1610/S_ _ _
①②③④

In-line cable connector
Mate with SA1610
SA1611/P_ _

Rear-nut mount
Mate with SA1610
SA1612/P_ _

Square flange
Mate with SA1610
SA1613/P_ _
④⑤

①Number of contact
②Cable outer diameter: Ⅰ:5-8mm,Ⅱ:8-12mm
②Colour:
B:Black
S:Silver
L:Blue (special order)
G:Green(special order)
R:Red (special order)

④1:solder,3:crimp
⑤Number of contact
⑥Colour:
B:Black
S:Silver
L:Blue (special order)
G:Green(special order)
R:Red (special order)
⑦1:solder,3:crimp

Material and spec

Material	Metal
IP Rating	IP67
Coupling Type	Push and Pull
Termination	Solder
Shell	Anodized aluminium
Insert material	PPS, max temperature 260℃
Contact material	Brass with gold plating
Termination	Solder
Cable outer diameter range	Ⅰ: 4-6.5mm Ⅱ: 5-8mm
Mating cycle	> 500
Temperature range	-40℃~+85℃
Insulation resistance MΩ	2000

Number of contact	2	3	4	5	7	9	10
Male contact face view
Rated current (A)	10	10	5	5	5	5	5
Contact diameter(mm)	1.5	1.5	1	1	1	1	1
Rated voltage(AC.V)	500	500	500	500	400	400	400
Test voltage(AC.V)1 min	1500	1500	1500	1500	1200	1200	1200
Contact resistance (mΩ)	2.5	2.5	5	5	5	5	5
Wire size (mm² /AWG)	≤2/14	≤2/14	≤0.785/18	≤0.785/18	≤0.785/18	≤0.785/18	≤0.785/18

Number of contact	2	3	4
Male contact face view
Rated current (A)	10	10	5
Contact diameter(mm)	1.5	1.5	1
Rated voltage(AC.V)	500	500	400
Test voltage(AC.V)1 min	1500	1500	1200
Contact resistance (mΩ)	2.5	2.5	5
Insulation resistance (MΩ)	2000	2000	2000
