Material and spec
| Material | Metal |
| IP Rating | IP66 |
| Coupling Type | Threaded coupling |
| Termination | Solder |
| Shell | Anodized aluminum |
| Insert material | PPS, max temperature 260℃ |
| Contact material | Brass with gold plating |
| Termination | Solder |
| Cable outer diameter range | See the drawing |
| Mating cycle | > 500 |
| Temperature range | -40℃~+85℃ |
| Insulation resistance MΩ | 2000 |
